Basic queries

Get a list of automation scenarios

Query:

GET /api/v1/automatons

Answer:

An array of all automation scripts in the project, including the following information about automatons:

• identifier;
• name;
• description;
• selected models

Get information about one automation scenario

Request:

GET /api/v1/automatons/:id

Answer:

Automation script representation in JSON format, including

• identifier;
• name;
• description;
• selected models;
• information about the constructed states and transitions

Create a new automation scenario

In the body of the request to create a new automation scenario, specify its representation in JSON format.

Required fields:

• model - model identifier;
• name - name of the new automation scenario.

Request:

POST /api/v1/automatons

{
  "model": "<model-id>",
  "name": "test-automaton-01",
  "description": "Automaton for sensor"
}

Answer:

Presentation of automation script in JSON format

Change automation script

In the body of the request to modify an existing automation script, specify the fields to be updated. fields to be updated.

Request:

PATCH /api/v1/automatons/:id

{
  "name": "test-automaton-02"
}

Answer:

Presenting the automation script in JSON format, taking into account the modified fields

Delete automation script

Request:

DELETE /api/v1/automatons/:id

Answer:

JSON representation of a remote automation script

Executing automation scripts on objects

Start automation script execution on the object

Request:

POST /api/v1/objects/:id/automatons/:automaton/start

Answer:

Information about the status and state of automaton execution at the moment of its start in JSON format

Stop automation script execution on the object

Request:

POST /api/v1/objects/:id/automatons/:automaton/stop

Answer:

Information about the status and execution state of the automaton at the moment of its stop in JSON format

Send event to running automation script

In the body of the request specify the identifier of the event that should be to generate in the automatism.

Required fields:

• event - event identifier.

Request:

POST /api/v1/objects/:id/automatons/:automaton/emit

{
  "event": "<event-id>"
}

Answer:

Information about the status of request execution
